BMW 5 Series Sedan (G60): Engines & technical data

TECHNICAL DATA FOR THE BMW 5 SERIES SEDAN.

¹
Powertrain type	Diesel – 48 Volt Mild-Hybrid
Power in kW (hp)	145 (197)
Torque in Nm	400
Transmission	8-speed, automatic
Drivetrain	All-wheel drive

¹
Cylinders	4
Displacement in cm3	1,995
Nominal power in kW (hp)/1/min	145 (197) / 4,000
Nominal torque in Nm/1/min	400 / 1,500 - 2,750


(Nominal) power/30-minutes-power in kW (hp)	- (-)-


Acceleration 0–100 km/h in s	7.3
Top speed in km/h	228

^{1 ,}²
Fuel consumption, combined WLTP in l/100 km	6 - 5.5
CO2 emissions, combined WLTP in g/km	157 - 143

³
Battery capacity in kWh	0.9


5,060 mm
1,900 mm
1,515 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,515
Width incl. mirrors (driver / passenger side) in mm	2,156 (1,081 / 1,075)
Wheelbase in mm	2,995 / 12.4
Vehicle curb weight in kg ⁴	1,905
Permissible gross weight in kg	2,460
Payload in kg	630
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	2,000 / 100
Luggage capacity in l	520
Tank capacity in l	60

¹
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW (hp)	153 (208) ⁶
Torque in Nm	330 ⁶
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm3	1,998
Nominal power in kW (hp)/1/min	140 (190) / 4,400 - 6,500
Nominal torque in Nm/1/min	310 / 1,500 - 4,000


(Nominal) power/30-minutes-power in kW (hp)	- (-)-


Acceleration 0–100 km/h in s	7.5
Top speed in km/h	230

^{1 ,}²
Fuel consumption, combined WLTP in l/100 km	6.4 - 5.7
CO2 emissions, combined WLTP in g/km	144 - 130

³
Battery capacity in kWh	0.9


5,060 mm
1,900 mm
1,515 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,515
Width incl. mirrors (driver / passenger side) in mm	2,156 (1,081 / 1,075)
Wheelbase in mm	2,995 / 12.3
Vehicle curb weight in kg ⁴	1,800
Permissible gross weight in kg	2,335
Payload in kg	610
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	2,000 / 100
Luggage capacity in l	520
Tank capacity in l	60

^{1 ,}⁷
Powertrain type	Petrol – Plug-in-Hybrid
Power in kW (hp)	220 (299)
Torque in Nm	450
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm3	1,998
Nominal power in kW (hp)/1/min	140 (190) / 4,400 - 6,500
Nominal torque in Nm/1/min	310 / 1,500 - 4,000

^{7 ,}⁸
(Nominal) power/30-minutes-power in kW (hp)	135 (184)
(Nominal) torque in Nm	250


Acceleration 0–100 km/h in s	6.4
Top speed in km/h	230
Electric top speed in km/h	140

^{1 ,}²
Fuel consumption, combined WLTP in l/100 km ⁹	0,8 - 0,6
CO2 emissions, combined WLTP in g/km ⁹	19 - 14
Energy consumption, combined WLTP in kWh/100 km ⁹	21,4 - 18,9
Electric range, WLTP in km ¹⁰	87 - 102


mm
mm
mm

¹
Powertrain type	Diesel – 48 Volt Mild-Hybrid
Power in kW (hp)	145 (197)
Torque in Nm	400
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm3	1,995
Nominal power in kW (hp)/1/min	145 (197) / 4,000
Nominal torque in Nm/1/min	400 / 1,500 - 2,750


(Nominal) power/30-minutes-power in kW (hp)	- (-)-


Acceleration 0–100 km/h in s	7.3
Top speed in km/h	233

^{1 ,}²
Fuel consumption, combined WLTP in l/100 km	5.6 - 5.1
CO2 emissions, combined WLTP in g/km	147 - 133

³
Battery capacity in kWh	0.9


5,060 mm
1,900 mm
1,515 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,515
Width incl. mirrors (driver / passenger side) in mm	2,156 (1,081 / 1,075)
Wheelbase in mm	2,995 / 12.3
Vehicle curb weight in kg ⁴	1,850
Permissible gross weight in kg	2,405
Payload in kg	630
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	2,000 / 100
Luggage capacity in l	520
Tank capacity in l	60

1 Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

2 Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

3 The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

4 The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

5 Trailer load depends on the vehicle options

6 Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value).

7 For plug-in hybrid: Electric drive depending on battery charging level.

8 For plug-in hybrid: At temperatures below freezing, the fully electric drive system is only available after a few kilometres of driving, once the battery has heated to operational temperature.

9 For plug-in hybrid: Weighted, combined (EC AC Charge Weighted)

10 Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.
